Cable Clamps - Screw Mount, P-Style - Compatible Cable Diameter Range - 19.1 mm | 0.750 in ; Operating Temperature Range - -40 - 85 °C | -40 - 185 °F ; Black
This P-style clamp holds cables, hoses, and pipes in place. It is easily installed by gripping and fastening the clamp to the chassis with a screw size 3/8;M8. Black is made from nylon and UL94 V-2-rated.
Loading...
| Quantity | Unit price |
|---|---|
| 1500 - 7499 | $0.4238 |
| 7500 - 14999 | $0.4046 |
| 15000 - 29999 | $0.3815 |
| 30000 + | $0.3357 |
Useful Information
Documents
Specifications
Imperial
Metric
| Maximum Compatible Cable Diameter | 0.750 in |
|---|---|
| Hole Diameter | 0.387 in |
| Compatible Screw Sizes (All) | 3/8. M8 |
| Operating Temperature Range | -40 - 185 °F |
| Overall Width | 0.875 in |
| Type | 1 |
| Style | P Clip |
| Material | Nylon |
| Adjustability | Fixed |
| Color | Black |
| Fitting Style | Clamp |
| Full Material | Nylon 6/6 |
| Material Flammability Standard | UL94 V-2 |
| Mounting Method | Screw |
