Edge Locking Support - #6 ; 6.4 mm | 0.250 in
Screw mount corner edge holding PCB support requires no slots or holes on PCB for maximum packaging density. Can be mounted to the corner or edge of PCB depending on supports orientation. Mounts to chassis with a metal #6 or M3.5 self-tapping screw.
Loading...
| Quantity | Unit price |
|---|---|
| 1000 - 9999 | $0.3823 |
| 10000 - 24999 | $0.277 |
| 25000 + | $0.254 |
Useful Information
Specifications
Imperial
Metric
| Body Diameter | 0.327 in |
|---|---|
| Maximum Operating Temperature | 185 °F |
| Maximum Panel Thickness A | 0.063 in |
| Minimum Operating Temperature | -40 °F |
| Panel Thickness A Range | 0.063 in |
| Spacer Length | 0.252 in |
| Color | Natural |
| Compatible Thread Sizes (All) | #6 |
| Hole A Fix Type | Snap Lock Fix |
| Hole B Fix Type | Female Thread Fix |
| Material | PA |
| Special Features | Self-Tapping Screw |
| Full Material | Polyamide 66 |
| Material Flammability Standard | UL94 V-2 |
