Quantity | Unit price |
---|---|
1000 - 4999 | $0.0689 |
5000 - 9999 | $0.062 |
10000 - 24999 | $0.0558 |
25000 + | $0.0503 |
File is successfully downloaded
Sorry, but the requested document is no longer available. please contact our customer support team for further assistance
Compatible Hole Diameter | 6.6 mm |
---|---|
Compatible Hole Diameter | 0.260 in |
Anchor Length | 9.7 mm |
Anchor Length | 0.380 in |
Head Diameter | 8.7 mm |
Head Diameter | 0.344 in |
Head Height | 0.6 mm |
Head Height | 0.022 in |
Operating Temperature Range | -40 - 85 °C |
Operating Temperature Range | -40 - 185 °F |
Colour | Natural |
Full Material | Nylon 6/6 |
Material Flammability Standard | UL94 V-2 |
Rivet Head Shape | Pan |
Rivet Fitting Style | Push-In |
