Scale Plates

In stock

Scale Plates are used to precisely and repeatedly place sliding clamps along linear guides or shafts. There are two variants available, each with a distinct mounting style. On the one hand, single scale plates and, on the other hand, double scale plates. Within each of them, there is a type of mounting type. Screw mounting type with drilled holes or adhesive mounting features an outline of the screw hole location, not drilled.

They feature a marked scale or grid pattern that runs along one or both edges, giving users an indication. It is durable and wear resistant.

These are widely employed in a variety of industrial applications such as automotive, aerospace, and medical equipment.

There are two variants available, each with a distinct mounting style.

Employed in a variety of industrial applications such as automotive, aerospace, and medical equipment.

Feature a marked scale or grid pattern that runs along one or both edges, giving users an indication.

Material: Stainless Steel, Aluminium Series Code: SR33977, SR33975, SR33976

Product Datasheet

Print page

Request a quote

For large volumes and customised products, add to your cart and click request a quote, orcontact usand we will respond within 2 working days.

66 results

Sort by

None

Product SKUs information
Price range	Availability	l2	Number of mounting holes	Material	l1	Type
R 77,4124 - R 103,2166	Request the lead time here	70.0	3.0	Aluminium	150.0	Single Scale

R 46,8012 - R 62,4016	Request the lead time here	40.0	2.0	Aluminium	50.0	Double Scale

R 59,3178 - R 79,0904	Request the lead time here	40.0	2.0	Stainless Steel	50.0	Single Scale

R 77,4124 - R 103,2166	Request the lead time here	70.0	3.0	Aluminium	150.0	Single Scale

R 224,0743 - R 298,7658	Request the lead time here	100.0	6.0	Aluminium	500.0	Single Scale

R 57,4131 - R 76,5508	Request the lead time here	90.0	2.0	Aluminium	100.0	Single Scale

R 55,9165 - R 74,5554	Request the lead time here	90.0	2.0	Aluminium	100.0	Single Scale

R 98,9083 - R 131,8778	Request the lead time here	95.0	3.0	Aluminium	200.0	Single Scale

R 98,9083 - R 131,8778	Request the lead time here	95.0	3.0	Aluminium	200.0	Single Scale

R 39,5905 - R 52,7874	Request the lead time here	40.0	2.0	Aluminium	50.0	Single Scale

R 44,8965 - R 59,862	Request the lead time here	40.0	2.0	Aluminium	50.0	Double Scale

R 59,3178 - R 79,0904	Request the lead time here	40.0	2.0	Stainless Steel	50.0	Single Scale

R 95,371 - R 127,1614	Request the lead time here	95.0	3.0	Aluminium	200.0	Single Scale

R 55,9165 - R 74,5554	Request the lead time here	90.0	2.0	Aluminium	100.0	Single Scale

R 37,9579 - R 50,6106	Request the lead time here	40.0	2.0	Aluminium	50.0	Single Scale

R 55,9165 - R 74,5554	Request the lead time here	90.0	2.0	Aluminium	100.0	Single Scale

R 71,8344 - R 95,7792	Request the lead time here	90.0	2.0	Aluminium	100.0	Double Scale

R 85,8475 - R 114,4634	Request the lead time here	90.0	2.0	Stainless Steel	100.0	Single Scale

R 87,8883 - R 117,1844	Request the lead time here	90.0	2.0	Stainless Steel	100.0	Single Scale

R 85,8475 - R 114,4634	Request the lead time here	90.0	2.0	Stainless Steel	100.0	Single Scale
