N/A - Compatible Hole Diameter - 19.1 mm | 0.750 in ; Compatible Panel Thickness Range - 0.8 - 2.8 mm | 0.031 - 0.109 in
This Solid Locking Plug is used to close off extra chassis holes, wire outlets, and access holes. It is dust, dirt, moisture resistant, corrosion, and vibration resistant. Designed to fit snugly with a finger and may be withdrawn and replaced as needed. Black, made from Nylon and UL94 V-2 rated.
Loading...
| Quantity | Unit price |
|---|---|
| 500 - 999 | $0.3216 |
| 1000 - 4999 | $0.1436 |
| 5000 - 9999 | $0.1425 |
| 10000 - 24999 | $0.1415 |
| 25000 + | $0.1334 |
Useful Information
Documents
Specifications
Imperial
Metric
| Full Material | Nylon 6/6 |
|---|---|
| Colour | Black |
| Material Flammability Standard | UL94 V-2 |
| Fitting Style | Push Fit |
| Hole Type | Round Hole |
| Overall Diameter | 0.984 in |
| Overall Height | 0.062 in |
| Compatible Hole Diameter | 0.750 in |
| Compatible Panel Thickness Range | 0.031 - 0.109 in |
